MHW35FS

VHF & UHF Masthead Amplifier with Fully Shielded Housing

Key Features
Frequency Range 174-230 MHz & 520-694 MHz
35dB UHF Maximum Gain
26dB VHF Maximum Gain
10dB Gain Control for UHF
16-12dB Tilt Control for VHF
Separate VHF & UHF Inputs or Combined Input
FM Radio 88-108 MHz Pass Through Selectable
4G/LTE Filtering
Fully Shielded Die-cast Housing
Weatherproof Housing
High Output Figure of 108dB IMR3 (DIN45004B)
Connectors: F-Type
Power Consumption: 80mA
Suitable Power Supply: PSK06 Series or PSK08 Series
